High-Performance 16-Port Ruijie Switch With 10G Uplink & Advanced
Layer 2 Management
The Ruijie RG-SF2920-16GT2XMG2XS-UP is a feature-rich Gigabit Layer
2 managed switch designed for SMBs, enterprise networks, and campus
environments. With 16x1G copper ports, 2x10G SFP+ uplinks, and
advanced management capabilities, it delivers high-speed
connectivity, scalability, and security for demanding networks.
Key Features & Benefits
High-Speed Networking – 16x Gigabit Ethernet ports + 2x10G SFP+
uplinks for seamless aggregation and backbone connectivity.
Advanced Layer 2 Management – Supports VLAN, QoS, ACL,
STP/RSTP/MSTP, and ERPS ring protection (sub-50ms failover).
Enhanced Security – Port security, DHCP Snooping, IP Source Guard,
and 802.1X authentication prevent unauthorized access.
Easy Cloud & Web Management – Web GUI, CLI, and SNMP for flexible
control + optional Ruijie Cloud platform for centralized
monitoring.
Energy-Efficient & Silent – Fanless design with IEEE 802.3az (EEE)
for reduced power consumption.
Technical Specifications
| Model | RG-SF2920-16GT2XMG2XS-UP |
|---|
| Ports | 16x 10/100/1000BASE-T, 2x 1G SFP, 2x 10G SFP+ |
| Switching Capacity | 56 Gbps |
| Forwarding Rate | 41.7 Mpps |
| Management | Web, CLI, SNMPv1/v2c/v3, RMON, LLDP |
| Security | ACL, Port Security, DHCP Snooping, IP Source Guard, 802.1X |
| QoS | 802.1p/DSCP priority, 4 queues per port |
| Power | 100-240V AC, <30W (non-PoE) |
| Dimensions | 440 x 180 x 44 mm (Rack-mountable) |
Ideal Use Cases
Enterprise Access Layer – Connects PCs, IP phones, and wireless APs
with Gigabit speeds.
Campus & Surveillance Networks – 10G uplinks handle high-bandwidth
traffic from IP cameras and servers.
SMB & Branch Offices – Easy-to-manage yet enterprise-grade
switching at an affordable price.
This Ruijie switch balances performance, security, and
cost-efficiency, making it a top choice for modern networks. For
datasheets, firmware, or bulk pricing, contact Ruijie authorized
partners today!
