Huawei S5731S-S48P4X-A Switch - 48x1G + 4x10G Ports , IStack &
Energy-Efficient
The Huawei S5731S-S48P4X-A is a high-performance Gigabit Ethernet
switch designed for enterprise networks, offering 48x1G RJ45 ports
+ 4x10G SFP+ uplinks for flexible connectivity. Ideal for
high-density access, campus networks, and small-to-medium business
(SMB) deployments, this switch ensures scalable bandwidth,
intelligent management, and energy efficiency.
Key Features & Benefits
✔ High-Speed Connectivity – 48x 10/100/1000BASE-T ports + 4x 10G
SFP+ fiber uplinks, eliminating bottlenecks for bandwidth-intensive
applications.
✔ Intelligent Stacking (iStack) – Supports virtual stacking of
multiple switches (up to 9 units) for simplified management and
redundancy.
✔ Energy-Efficient Design – IEEE 802.3az (EEE) compliance and smart
power-saving modes reduce operational costs.
✔ Enterprise-Grade Security – Features ACL, port isolation, DHCP
snooping, and MACsec encryption (optional) for secure data
transmission.
✔ Cloud & SDN Ready – Compatible with Huawei CloudEngine SDN and
eSight NMS for centralized monitoring and automation.
✔ Silent Operation – Fanless design ensures quiet performance in
office environments.
Technical Specifications (Huawei S5731S-S48P4X-A Switch)
| Parameter | Specification |
|---|
| Ports | 48x 10/100/1000BASE-T (RJ45), 4x 10G SFP+ |
| Switching Capacity | 136 Gbps |
| Forwarding Rate | 102 Mpps |
| Stacking | Huawei iStack (up to 9 units) |
| Power Supply | AC 100-240V, optional dual PSU for redundancy |
| Security | ACL, 802.1X, MACsec, DHCP Snooping |
| Management | CLI, Web, SNMP, eSight, OpenFlow (SDN) |
| Dimensions (WxDxH) | 442 x 220 x 43.6 mm |
| Operating Temp. | 0°C to 45°C (32°F to 113°F) |
Ideal Use Cases
✅ Enterprise Access Layer – Reliable connectivity for IP phones,
PCs, and wireless APs.
✅ Data Center Edge – High-speed uplinks for server and storage
access.
✅ Surveillance Networks – Supports IP cameras with PoE+ models
(check PoE variants).
✅ SDN & Cloud Integration – Future-proof for software-defined
networking.
This Huawei gigabit switch balances performance, scalability, and
power efficiency, making it a cost-effective solution for modern
business networks.
